Hikvision-DS-KH8301-WT-0.3MP-7-Touch-Screen-Indoor-Station

System parameters

• Processor: High-Performance Embedded SOC Processor
• Operation system: Embedded Linux Operation System

Video parameters

• Video compression standard: H.264
• Resolution: 1024 x 600
• Video frame rate: PAL: 25 fps, NTSC: 30 fps

Display parameters

• Display screen: 7-Inch Colourful TFT LCD
• Display resolution: 1024 × 600
• Operation method: Capacitive Touch Screen, Touch Key
• Operation interface: Flattened UI Operation Interface

Audio parameters

• Audio input: Built-in Omnidirectional Microphone
• Audio output: Built-in Loudspeaker
• Audio compression standard: G.711 U
• Audio compression rate: 64 Kbps
• Audio quality: Noise Suppression and Echo Cancellation

Network parameters

• Ethernet: 10/100 Mbps Self-Adaptive Ethernet
• Network protocol: TCP/IP, RTSP

Alarm parameters

• Alarm input 8-ch Alarm Input Sensor

Device interfaces

• Network interface: 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
• RS-485: 1 RS-485 Half-Duplex Port
• I/O output 2 *Note：Alarm output is reserved.
• TF card (micro SD card) TF Card, Support Max. 32GB

General

• Memory: 256 M
• Power supply: 24 VDC, Power Over Network Cable (DS-KAD606, DS-KAD612), 12 VDC
• Power consumption: ≤10 W
• Working temperature: -10° C to + 55° C (14° F to 131° F)
• Working humidity: 10% to 90%
• Dimensions (L × W × H): 217 mm × 142 mm × 26 mm (8.5″ × 5.6″ × 1.0″)
• Certification: FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
