HPE ProLiant DL20 Gen10 E-2236 1P 16GB-U S100i 4SFF 500W RPS Server

KSh228,480


HPE ProLiant DL20 Gen10 solution – rack-mountable – Xeon E-2236 3.4 GHz – 16 GB – no HDD
Type Server – rack-mountable
Height (Rack Units) 1U
Server Scalability 1-way
Processor 1 x Intel Xeon E-2236 / 3.4 GHz (4.8 GHz) (6-core)
Processor Socket LGA1151 Socket
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache
Cache Memory 12 MB L3 Cache
Cache Per Processor 12 MB
RAM 16 GB (installed) / 64 GB (max) – DDR4 SDRAM – ECC – PC4-21333
Storage Controller RAID (SATA 6Gb/s) (HPE Smart Array S100i SR Software RAID)
Server Storage Bays Hot-swap 2.5″
Hard Drive No HDD
Optical Storage No optical drive
Graphics Controller Matrox G200
Networking GigE
Power AC 120/230 V (50/60 Hz)
Power Redundancy Yes
Dimensions (WxDxH) 43.46 cm x 38.22 cm x 4.32 cm
Weight 7.88 kg
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty Limited warranty – parts and labour – 3 years – on-site – response time: next business day

Share it:
General
Hot-Swap Bays Qty 4
Product Form Factor Rack-mountable – 1U
Server Scalability 1-way
Type Server
Cache Memory
Cache Per Processor 12 MB
Installed Size L3 Cache – 12 MB
Dimensions & Weight
Depth 38.22 cm
Height 4.32 cm
Weight 7.88 kg
Width 43.46 cm
Environmental Parameters
Humidity Range Operating 8 – 90% (non-condensing)
Max Operating Temperature 35 °C
Min Operating Temperature 10 °C
Sound Emission 27 dBA
Environmental Standards
ENERGY STAR Certified Yes
Expansion / Connectivity
Bays 1 (total) / 1 (free) x external 5.25″ ¦ 4 (total) / 4 (free) x hot-swap 2.5″ SFF
Interfaces 1 x VGA ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x LAN (Gigabit Ethernet) / HPE iLO ¦ 5 x USB 3.0 (2 front, 2 rear, 1 internal)
Slots 1 (total) / 1 (free) x PCIe 3.0 x16 – full-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 – low-profile (x8 mode)
Graphics Controller
Graphics Processor Matrox G200
Video Interfaces VGA
Hard Drive
Type No HDD
Manufacturer Warranty
Service & Support Limited warranty – parts and labour – 3 years – on-site – response time: next business day
Miscellaneous
Compliant Standards AES, FIPS 140-2, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, Redfish API, UEFI
Included Accessories HPE Short Friction Rail kit
Monitor
Monitor Type None.
Networking
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controller HPE 332i
Ethernet Ports 2 x Gigabit Ethernet
Features Wake on LAN (WoL), PXE support
Interface (Bus) Type PCI Express x2
Remote Management Controller Integrated Lights-Out 4
Optical Storage
Type No optical drive
Power
80 PLUS Certification 80 PLUS Platinum
Device Type Power supply
Efficiency 94%
Installed Qty 1
Power Provided 500 Watt
Power Redundancy Yes
Voltage Required AC 120/230 V (50/60 Hz)
Processor / Chipset
CPU Intel Xeon E-2236 / 3.4 GHz
CPU Qty 1
CPU Socket LGA1151 Socket
CPU Upgradability Upgradable
Max CPU Qty 1
Max Turbo Speed 4.8 GHz
Number of Cores 6-core
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache
RAM
Configuration Features 1 x 16 GB
Effective Memory Speed 2666 MHz
Features Unbuffered, dual channel memory architecture
Form Factor DIMM 288-pin
Installed Size 16 GB / 64 GB (max)
Memory Specification Compliance PC4-21333
Rated Memory Speed 2666 MHz
Slots 4 (Total) / 3 (empty)
Technology DDR4 SDRAM – ECC
Storage Controller
Channel Qty 4
Controller Interface Type SATA 6Gb/s
RAID Level RAID 0, RAID 1, RAID 5, RAID 10
Storage Controller Name HPE Smart Array S100i SR Software RAID
Type 1 x RAID
